Volksplane VP-1

by Evans
3.4
14
Volksplane VP-1 - Photo #1

According Volksplane, the VP 1 is perhaps the simplest, least expensive wood aircraft you can build. Today there is a VP1 flying in practically every country on the globe.

The Volksplane slogan is U-Build U-Fly . The photo above shows an VP-1 in Sweden.

Volksplane plans and material kits are available from Aircraft Spruce starting at $59.00,

From Aircraft Spruce:
Aircraft Spruce & Speciality is the exclusive distributor for VP-1 materials kits. The Volksplane was designed and prototyped by Bud Evans in 1968. The aircraft is inexpensive, easy to build, and fun to fly. The fuselage is all wood, with three bulkheads, four longerons, flat plywood and some vertical stiffners. Wings are wood frames covered with fabric. The only parts requiring welding are the control stick, strut ends and stabilizer horn. The only sheetmetal work is in the elevator trim tab. Over 1000 of these single planes are flying. The aircraft is ideally suited for Volkswagen engines in the 1500 to 1834 cc range. We can supply complete materials kits from stock. Free kit list on request.

Specifications

MTOW:
750 lbs (340 kg)
Stall speed:
35 kts (40 mph) (65 kph)
Cruise speed:
70 kts (81 mph) (130 kph)
VNE:
100 kts (115 mph) (185 kph)
Climb:
200 ft/min (1 m/s)
Take-off distance:
1312 ft (400 m)
Landing distance:
984 ft (300 m)
Engine:
1600 VW (peacock conversion)
Fuel consumption:
3 GPH (11.4 LPH)

Watch 1 Video about the Volksplane VP-1
